KR-VH1000i

Horizontal / Vertical

The KR-VH1000i combines vertical and horizontal milling in one rigid, Meehanite-cast machine built for serious workshop output. With 5HP motors on both spindles, hardened and ground ways, and generous table travels, it delivers consistent accuracy across a wide range of metals and job types. A proven, serviceable platform designed for reliability, repeatability, and long-term value.

Highlights

Made In Taiwan

Delivering the robustness and high precision we’ve all come to expect from Taiwanese-made machine tools

Hardened & Ground Slideways

Ensures smooth travel, reduced wear, and long-term accuracy on X, Y, and Z axes

Dual Milling Capability

Switch easily between vertical turret and horizontal milling for maximum machining flexibility

Rigid Meehanite Construction

Heavy cast-iron build maximises stability, ideal for demanding cuts and repeatable accuracy

Operator-Friendly Controls

Pendant-mounted switches, quill feed options, and variable speed head for practical day-to-day operation

Feature Summary

The KR-VH1000i is built for Australian workshops that demand versatility without compromising rigidity. Its biggest advantage is simple: you get genuine vertical and horizontal milling capability in one footprint. That means more jobs completed on one machine and less time tied up in changeovers.

The machine is anchored by a robust Meehanite cast-iron frame, giving it the mass and damping needed for stable, chatter-free cutting. That foundation supports hardened and ground slideways across all three axes, critical for longevity and predictable accuracy. These are practical engineering decisions that matter on the shop floor, especially when the work shifts between heavy roughing and precise finishing.

Both spindles run 5 HP motors, giving the KR-VH1000i the muscle to remove material efficiently. The vertical head offers a wide speed range (70–3600 rpm) while maintaining smooth control for small-tool operations. The horizontal spindle provides the rigidity required for deep-slotting, slab milling, and other high-load tasks. Together, they cover the broadest possible spectrum of workshop jobs.

Travels are generous for a turret-style mill: 860mm in X and 400mm in Y exceed many alternatives in this size class, giving you more usable table area and fewer compromises with fixturing. The quill diameter is a substantial 105mm, placing it at the upper end of the market for rigidity and drilling performance.

Operator-focused details round out the package. A pendant arm with locking screws positions controls right where you need them. Rapid traverse on the Z-axis reduces downtime during tool changes and setup adjustments. The machine includes power feeds on X and Y, a hardened table surface, rubber way covers, levelling hardware, and a full toolbox.

Specifications

Specification Value
Table Size 254 × 1372 mm
Longitudinal Travel (X) 860 mm
Cross Travel (Y) 400 mm
Knee Travel (Z) 460 mm
Ram Travel 450 mm
Quill Feed 0.038 / 0.076 / 0.152 mm
Quill Travel 127 mm
Quill Diameter 105 mm
Vertical Spindle Motor 5 HP
Horizontal Spindle Motor 5 HP
Spindle Speed (Vertical) 70–3600 rpm (60Hz) / 60–3000 rpm (50Hz)
Spindle Taper #40
Turret Swivel 360°
Head Tilt (Front–Back) -40° to +45° (optional)
Head Tilt (Left–Right) -90° to +90°
Spindle Nose to Table 0–520 mm
Spindle Centre to Column 450 mm
T-Slots 3 × 15.9 mm
Machine Weight 1,745 kg
Overall Height 2,540 mm
Coolant Pump Motor 1/8 HP

Standard Inclusions

  • LED work light
  • Z-axis rapid traverse & feed
  • X & Y axis power feeds
  • Steel chip tray
  • Rubber way covers (front & rear of table)
  • Pendant-arm operator switch console (swivel + locking screws)
  • Toolbox with tools
  • Levelling screws and blocks
  • Hardened & ground table
  • Dovetail slideways on X, Y, Z axes

Optional Extras

  • Spindle guard
  • Digital readout system
  • Air power drawbar
  • Inverter head
